xGenConnect Installation and Programming Guide 3
Product
Description
EN grade
NXG-9-RF-Z-BO
xGenConnect board, 8 zones, 8 partitions, max. 48 zones,
with IP, Zwave and LoNa Receiver on-board, for poly housing
2
NXG-1820-EUR
3.5 inch Touchscreen keypad, multilingual
2/3
NXG-183x-EUR
LCD keypad, multilingual
2
NXG-208-G3
8 zone expander
2/3
NXG-208N
xGenConnect 8 zone expander board
2
NXG-216N
xGenConnect 16 zone expander board
2
NXG-220-G3
20 zone expander
2/3
NXG-504
4 relay output expander
2/3
NXG-508N
xGenConnect 8 relay expander board
2
NXG-510
10 relay output expander
2/3
NXG-001
Plastic housing /w tamper switch
2
NXG-005
Pry-off tamper switch incl. metal U-bracket
2/3
NXG-003
Housing /w tamper sw – Metal EN Grade 2
2
NXG-003-DIN
DIN-rail mounting kit
2/3
NXG-868
Wireless expander 868 MHz Gen 2
2
NXG-433
Wireless expander 433 MHz
2
NXG-7002(-SIM)
4G/Wi-Fi communication expander (- SIM includes SIM card)
2
Mains Power Specifications
Mains input voltage
230 VAC +10%, −15%, 50 Hz ±10%
Current consumption at 230 VAC
240 mA max.
Transformer output:
NXG-4, NXG-8(E)
16.3 VAC 40 VA
NXG-9
20 VAC 40 VA
Installation Instructions for Service Persons
An appropriate disconnect device, to control the mains power to this device, is to
be provided as part of building installation according to the local wiring rules.
Power Supply Specifications
Power supply type
EN 50131-6 Type A for indoor use inside the
supervised premises
Power supply voltage
13.8 VDC ± 0.4 V
Power supply current
2 A max. at 13.8 VDC ± 0.4 V
Main board consumption:
NXG-4
130 mA at 13.8 VDC ± 0.4 V
