4 xGenConnect Installation and Programming Guide
NXG-8(E)
125 mA at 13.8 VDC ± 0.4 V
NXG-9
150 mA at 13.8 VDC ± 0.4 V
Maximum system current available:
2000 mA at 13.8 VDC ± 0.4 V
Auxiliary power output (AUX. POWER):
13.8 VDC ± 0.4 V, 600 mA max.
Auxiliary power output (bus):
13.8 VDC ± 0.4 V, 600 mA max.
Battery power output (BAT):
NXG-4
13.8 VDC ± 0.2 V, 350 mA max.
NXG-8(E)
13.8 VDC ± 0.2 V, 350 mA max.
NXG-9
13.8 VDC ± 0.2 V, 570 mA max.
Battery type
Certified sealed lead acid rechargeable.
7.2 Ah 12 V nominal
12 Ah 12 V nominal (NXG-8 and NXG-9 only)
18 Ah 12 V nominal (NXG-8 only)
Minimum energy level of the battery in its charged
state is 100%
Minimum voltage
9.45 VDC
Over-voltage threshold
16.3 VDC ± 5%
Maximum voltage at power supply, auxiliary
power output and battery power output
14.5 VDC
Battery low condition
11.3 to 11.8 VDC
Battery disconnect voltage
9.77 VDC
Maximum ripple voltage V, p-p
200 mV typical, 550 mV max.
General Features
Code combinations:
xGenConnect
From 10,000 (4 digits) to 100,000,000 (8 digits)
Maximum user number:
NXG-4
40
NXG-8, NXG-9
100
NXG-8E
256
User Permissions:
NXG-4
32
NXG-8, NXG-9
64
NXG-8E
128
Onboard zones:
NXG-4
4 (default); 8 if zone doubling enabled.
NXG-8(E), NXG-9
8 (default); 16 if zone doubling enabled.
Maximum zone number:
NXG-4
16
NXG-8, NXG-9
48
NXG-8E
192
