Interlogix xGenConnect NXG-8-Z-B0 User Manual

xGenConnect Installation and Programming Guide 5
Additional inputs:
NXG-4, NXG-8(E)
1: box tamper
NXG-9
2: box tampers
End-of-line resistor
820 Ω (2-wire smoke)
3.3 kΩ, 4.1 kΩ, 4.7 kΩ (alarm)
3.74 kΩ, 6.98 kΩ (zone doubling)
Onboard outputs:
NXG-4
4: bell, strobe, siren and power outputs
NXG-8(E), NXG-9
5: bell, strobe, siren and power outputs
Maximum output number
32
Maximum action number
32
Partitions:
NXG-4
4
NXG-8(E), NXG-9
8
Maximum keypad:
NXG-4
16
NXG-8(E), NXG-9
24
Maximum expander modules, incl keypads:
NXG-4
24
NXG-8(E), NXG-9
32
Non-volatile Memory
Event log capacity
1024
Data retention (log, program settings)
10 years
Ethernet Connection (IP only)
Supported standard
IEEE 802.3u
Speed
10BASE-T or 100BASE-TX
Duplex
Half-duplex and full-duplex
Cabling
FTP (foiled twisted pair) Cat 5e cable or better
xGenConnect Bus
Type
4 wire RS485 bus
High common mode tolerance (25V)
Capacity
Up to 32 devices
Range
800 m
Cable flammability rating
VW-1
