Intermec EasyCoder PD4 Service Manual

6 Intermec EasyCoder PD4—Service Manual
Chapter 1—Models and Options
Weight (excluding media and options) ≈ 13 kg (28.7 pounds)
Environment
Operating Temperature +5°C to +40°C (+41°F to +104°F)
Storage Temperature -20°C to +50°C (-40°F to +122°F)
Operating Humidity 30 to 85% non-condensing. Free air
Storage Humidity 10 to 90% non-condensing. Free air
Electronics
Microprocessor 16 bit
Standard Memory 2MB fl ash + 2MB DRAM
Real-time Clock Yes
1
Date/time stamp
Power Supply
AC Voltage 100/240 VAC, 50 to 60 Hz
Power Consumption (approx.) Stand-by 5W; Peak 140W
Sensors
Label Gap/Black Mark/Out of Media Yes Moveable, left-aligned
Printhead Lifted Yes
Ribbon End Yes
Label taken Yes
1
Controls
Control Lamps 3; Power, Ready, and Error Bi-color
Display Yes
1
Graphic LCD with background light
Control Keys 3; Feed, Pause, and Cancel
Beeper Yes
Data Interfaces
Serial 1 x RS-232 + 1 x USB
Parallel Yes
Accessories and Options
Integral Self-strip Unit with Liner
Takeup
Option
1
For peel-off operation
Cutter Option
1
2MB Flash Memory Expansion Card Option
1
Keyboard/Display Unit Option
EasyLAN 10 External Ethernet
Adapter
Option
1
/. Models with graphic display front panel only.
