70 Intermec EasyCoder PD4—Service Manual
Chapter 12—Main Board
12.3 Connections
EasyCoder PD4, no display, 203.2 dpi
CN11
Ribbon out
CN23
RS-232
CN14
Headlift
CN8
Black
mark
CN9
See
through
JP4
USB
CN21
Centronics
CN7
Motor
CN28
Power
CNA1 & CNB1
Printhead
