Intermec EasyCoder PD4—Service Manual 71
Chapter 12—Main Board
EasyCoder PD4, display, 203.2 dpi
CN11
Ribbon out
CN23
RS-232
CN12
Strip module
CN17
Rewinder full
CN14
Headlift
CN8
Black
mark
CN9
See
through
CN22
LCD Panel
JP4
USB
CN21
Centronics
CN19
Cutter
CN7
Motor
CN28
Power
CNA1 & CNB1
Printhead
CN3 & CN4
Memory
expansion card
