Intermec EasyCoder PD4 Service Manual

Intermec EasyCoder PD4—Service Manual 5
Chapter 1—Models and Options
1.3 Technical Specifications
Printing
Print Technique Direct Thermal/Thermal Transfer
Printhead Resolutions 8 dots/mm (203.2 dpi) or
11.81 dots/mm (300 dpi)
1
Print Speed (variable) 50.8 to 152.4 mm/sec. (2 to 6 in/sec.)
50.8 to 101.6 mm/sec. (2 to 4 in/sec.)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Width 25 to 104 mm (1 to 4.09 in)
25 to 106 mm (1 to 4.17 in) 8 dots/mm 11.81 dots/mm
Print Length (max) 1,270 mm (50 in)
558.8 mm (22 in)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Print Directions 4
Media
Media Width 25 to 118.0 mm (1 to 4.65 inches)
Media Roll Diameter (max) 212 mm (8.35 inches)
Media Roll Core Diameter 38.1 to 76.2 mm (1.5 to 3 in)
Media Thickness 60 µm to 250 µm (2.3 to 9.8 mils)
Transfer Ribbon
Material Wax, hybrid, or resin
Winding Ink on either inside or outside
Ribbon Width 30 to 110 mm (1.18 to 4.33 in)
Ribbon Roll Diameter (outer) 76 mm (2.99 in) Equivalent to 450 m (1,471 ft) of
ribbon at ribbon thickness 8 µm
Inner Core Diameter 25.2 to 25.6 mm (1.00 inches)
Modes of Operation
Tear-Off (Straight-through) Yes
Peel-Off (Self-strip) Optional
Cut-Off Optional
Firmware
Operating System ESim v5.xx
Latin Fonts 5 resident alphanumeric fonts.
Windows bitmap fonts can be down-
loaded.
Asian Fonts Asian fonts can be downloaded:
GB 2312-80
Chinese Big5 level 1 & 2
KS X 11001:1992
JIS X0208:12977
Chinese
Chinese
Korean
Japanese
Built-in bar code symbologies (stan-
dard)
34
Physical Measures
Dimensions (W × L × H) 276 × 454.6 × 283.0 mm
(10.85 × 17.9 × 11.2 in)

Intermec EasyCoder PD4 Specifications

General

Brand	Intermec
Model	EasyCoder PD4
Category	Label Maker
Language	English
