Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 115
Chapter 9—Label Taken Sensor
9.2 Replacement
The LTS kit consists of a sensor with cable, a screw, and bracket. To replace
a faulty LTS, proceed as follows.
• Switch off the power and disconnect the power cord.
• Remove the bottom plate/right-hand door assembly, which is held to the
center section and power supply unit by a total of six #T20 Torx screws,
see Chapter 4.1.
When the bottom plate is removed, the power supply becomes exposed.
It contains wires and circuits with high voltage. For safety reasons, the
power cord must be disconnected before the bottom plate is removed!
• Disconnect the LTS cable from the CPU board. (It is not necessary to
remove the front/left-hand cover.)
• Remove the #T10 Torx screw that holds the bracket and sensor.
• Peel out the cable from the grooves in the center section, taking note
how the cable runs.
• Fit a new LTS assembly in reverse order.
• Start up the printer, enter the Setup Mode and adjust the sensitivity of
the new LTS as described in Chapter 9.3.
9.3 Activating the LTS
In Fingerprint, the label taken sensor is enabled using the instruction
LTS& ON.
In IPL, the self-strip mode must be enbled. This can also be done by
executing the following commands:
<STX>R<ETX> (Enter print/confi guration mode)
<STX><SI>t1<ETX> (Enable self-strip)
