Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 11
Chapter 1—Models and Options
Printing
Print Technique Direct Thermal (Thermal Transfer as option)
Printhead Resolution 8 dots/mm (203.2 dpi)
Print Speed (variable) 100 to 200 mm/sec. (approx. 4 to 8 in./sec.)
Print Width (max) 56 mm (2.2 in.) = 448 dots
Print Length (max) 32767 dots = 409.5 cm (161.25 in.)
1
Media Width (min/max) 25 to 60 mm (1.00 to 2.36 in.) Standard edge guide
Media Width (min/max) 40 to 60 mm (1.57 to 2.36 in.) Quick-Load guides
Media Roll Diameter (max) 213 mm (8.38 in.) Short door/no takeup
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or 76 mm (3 in.)
Ribbon Width (min/max) 25 to 60 mm (1 to 2.36 in.)
Ribbon Roll Diameter, Outer (max) 65 mm (2.44 in.) 240-300 m (787-985 ft)
Ribbor Roll Core Diameter, Inner 25.4 mm (1 in.)
Print Directions 4
Modes of Operation
Tear Off (Straight-through) Yes
Peel Off (Self-strip) Optional With liner takeup unit
Firmware (Fingerprint)
Operating System Intermec Fingerprint v8.10 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Built-in scaleable fonts (std) 15 Unicode fonts
2
Built-in bar code symbologies (std) 45
Startup Program (std) Intermec Shell v8.0
Firmware (IPL)
Operating System IPL v2.10
Built-in scaleable fonts (std) 13 scaleable + 21 simulated bitmap
Built-in bar code symbologies (std) 31
Physical Measures
Dimensions (W×L×H) 194×397×178 mm (7.64×15.63×7.00 in.) With long side door
Weight (excluding media) approx. 5.5 kg (12 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Humidity 20 to 80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets (for 4 or 8 MB each) Std. 1 × 4MB
On-board SDRAM SIMM 1 socket (for 8 or 16 MB) Std. 1 × 8MB
Power Supply
AC Voltage 90 to 265 VAC, 45 to 65Hz
PFC Regulation IEC 61000-3-2
Power Consumption Standby 15W; Peak 300W
Sensors
Label Gap/Black Mark/Out of Media Yes 5 fi xed positions
Printhead Lifted Yes
1.2 EasyCoder PF2i Specifications
