Intermec EasyCoder PF2i Service Manual

12 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 1—Models and Options
Ribbon End/Ribbon Low Yes (thermal transfer model only)
Controls
Control Lamps 3
Display 2 × 16 character LCD with background light
Keyboard Fingerprint: 22 keys; IPL: 7 keys Membrane-switch type
Print or Feed/Pause button 1
Beeper Yes
Data Interfaces
Serial 1×RS-232 + 1×USB USB not supp. by IPL
Bar Code Wand 1 Not supported by IPL
Connection for Interface Boards 1 + 1 1 EasyLAN + 1 other
Memory Card Adapter 1 CompactFlash cards
Accessories and Options
Thermal Transfer Mechanism Option
Integral Self-strip Unit w. Liner Takeup Option For peel-off operation
Rotating Media Supply Hub Option Replaces supply post
3-inch Adapter Option For media supply hub
Short Side Door Option
3
Long Side Door Option
3
Label Taken Sensor Option
Real Time Clock Option (not IPL) 10+ years life
RS-232 Interface Cable Option
Parallel Interface Cable Option
IEEE 1284 Parallel Interface Board Option
Double Serial Interface Board Option (not IPL)
Serial/Industrial Interface Board Option (not IPL)
EasyLAN Ethernet Interface Option Model EasyLAN100i2
EasyLAN Wireless Interface Option Model Wireless 100i2
External Alphanumeric Keyboard Option (not IPL)
CompactFlash Cards Option 8MB to 1GB
CompactFlash Card Protection Plate Option
1
/. The max. print length is also restricted by the amount of free SDRAM memory.
2
/. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3
/. Type of door fi tted at delivery depends on model.
