120 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 10—Paper Cutter
Cable
Bracket
Cable Cover
Connect to J51 on CPU
board
#T20 Torx screws
and washers (×3)
Existing #T20 Torx screw
Clip
Fitting a cutter on an EasyCoder PF4i
