192 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 14—Interfaces
Connector Configuration
The IEEE 1284 board has a standard 36pin IEEE 1284 B socket with the
following confi guration:
Pin Signal Remark
1 DSTROBE
2 DATA 0
3 DATA 1
4 DATA 2
5 DATA 3
6 DATA 4
7 DATA 5
8 DATA 6
9 DATA 7
10 ACK
11 BUSY
12 PE
13 SELECT
14 AF
15 N/C
16 GND
17 SCREEN
18
.
External +5VDC max 500 mA (automatic switch-
off at overload, short-circuit protected)
19 GND
20 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 GND
27 GND
28 GND
29 GND
30 GND
31 INIT
32 ERROR
33 N/C
34 N/C
35 N/C
36 SELECTIN
