Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 197
Chapter 14—Interfaces
Network extension cable
EasyLAN Ethernet interface
board
Light guideCable tie Screw and spacer
Optional interface board
(Serial/Industrial,
Double Serial, or
IEEE 1284 Parallel)
CPU board
Serial number label
RJ-45 Ethernet
connector
