44 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 3—Covers and Doors
Short door
Magnetic lock
Front hinge
Rear hinge
EasyCoder PF4i with a short side door.
Magnetic lock
Front hinge
(rear hinge hidden)
Long door
EasyCoder PF4i with a long side door.
EasyCoder PF4i
