Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual 81
Chapter 7—Print Mechanism
Stepper motor
#T20 Torx screws (×4)
Platen roller pulley
Liner drive roller pulley
Platen roller belt
Liner drive roller belt
Rubber dampeners (×4)
The stepper motor, the dampeners, the belts, and the pulleys are identical
in EasyCoder PF2i,PF4i, and PF4i Compact Industrial.
