90 Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Chapter 7—Print Mechanism
bw
fw
Media guide assy.
#T20 Torx screws (×3)
Cable guard
(EasyCoder PF4i only)
Cable guard snap-lock
(EasyCoder PF4i only)
Grounding spring
EasyCoder PF4i and PF4i Compact Industrial
