Intermec EasyCoder PX6i User Manual

EasyCoder PX6i User’s Guide (Fingerprint version) 99
Chapter 10 — Troubleshooting
Display Messages and LED Indications
Error/Event IRI Error No. Comment
Operational On 0 No error
Out of paper Blink 1005
Next label not found Blink 1031
Label not taken Blink
Out of transfer ribbon Blink 1027
Transfer ribbon is installed Blink 1058
Head lifted Blink 1022
Cutter does not respond Blink 1059
Cutter error1 Blink 1701
Cutter error2 Blink 1702
Cutter error3 Blink 1703
Cutter open Blink 1704
Lss too high Blink 1007
Lss too low Blink 1008
Testfeed not done Blink 1606
Pause Mode entered Blink
Setup Mode entered Blink Including interactive setup from
Fingerprint/Direct Protocol
IP link error Blink See note 1, 2, and 3
IP confi guration error Blink See note 1, 3, and 4
Generic DP error Blink See note 5
Press any key to continue Blink See note 6
Application load error Blink See note 7
IRI blink by application Blink Set by Fingerprint instruction
SYSHEALTH
IRI off by application Off Set by Fingerprint instruction
SYSHEALTH
Application break Off See note 8
Printhead not found Off
Rebooted Off
Initializing Off Set at startup until operational
Printer crash Off See note 3 and 9

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
