EasyCoder PX6i User’s Guide (Fingerprint version) 7
Chapter 2 — Installation
Front View
At the front of the printer are the display window, the indicator lamps,
and the keyboard. These features allow the operator to control and set up
the printer manually.
The front door is held by a snap-lock. Open the front door to view the
various parts on the printer’s front.
Refer to Chapter 9 “Options” for information on possible optional
devices fi tted on the printer’s front.
Side door
Indicator lamps
Display window
Keyboard
Front door
Print mechanism
Connector
for optional
cutter
