EasyCoder PX6i User’s Guide (Fingerprint version) 131
Appendix B — Media Specifi cations
Tickets with Gaps
⇐ a ⇒ Media Width
Maximum: 170 mm (6.69 inches)
Minimum: 76 mm (3.00 inches)
⇐ b ⇒ Copy Length
Maximum:
8 dots/mm (203.2 dpi): 6,143 mm (241 inches)
11.81 dots/mm (300 dpi): 4,162 mm (163 inches)
provided there is a suffi cient amount of free SDRAM memory
Minimum (without LTS): 8.0 mm (0.32 inches)
Minimum (with LTS): 12.0 mm (0.47 inches)
⇐ c ⇒ LSS Detection Position
Variable, see Chapter 12.
⇐ d ⇒ Detection Slit Length
The length of the detection slit (excluding corner radii) must be mini-
mum 2.5 mm (0.10 inches) on either side of the LSS detection position
(e).
⇐ e ⇒ Detection Slit Height
Maximum: 25.0 mm (0.98 inches)
Recommended: 1.6 mm (0.06 inches)
Minimum: 1.27 mm (0.05 inches)
Opacity
Max opacity difference: 48%
Media Type Setup
• Ticket (w gaps)
Note: Do not allow any perforation to break the edge of the
media as this may cause the media to split and jam the printer.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
