Intermec EasyCoder PX6i User Manual

#LOSED
/
P
E
N
EasyCoder PX6i User’s Guide (Fingerprint version) 117
Chapter 12 — Adjustments
Printhead Pressure
The pressure of the thermal printhead against the ribbon or direct
thermal media is factory adjusted. However, the use of thicker or thinner
media than normal could require the printhead pressure to be readjusted.
Turn the adjustment knob clockwise for increased pressure, or counter-
clockwise for less pressure. Print a few labels, preferably test labels (see
Chapter 6, “Setting Up the Printer”), and check the printout. Increased
pressure generally gives a darker printout and vice versa. Repeat until the
desired result is obtained.
To fi nd the basic setting, turn the knob counterclockwise until there is
no pressure left. Test with a piece of media under the printhead. You
should be able to pull it out without more than just a little resistance.
Then turn the knob fi ve full turns clockwise. Fine-adjust using the trial-
and-error method.
Do not use a higher printhead pressure than necessary,
because it may increase the wear of the printhead and
shorten its life.
Knob

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
