EasyCoder PX6i User’s Guide (Fingerprint version) 25
Chapter 4 — Media Load
Cut-Off
The EasyCoder PX6i can print on labels, tickets, tags, and continuous
stock in various forms. This section describes the case when the media is
to be cut off by an automatic paper cutter (option).
Use the <Feed> key (see fi gure #14) when loading the same type of
media as before. When switching to a new type of media or if the printer
does not feed out the media properly, simultaneously press the <Shift>
and <Feed> keys to perform a “testfeed.”
Cut-off can be used for:
• Non-adhesive continuous stock
• Self-adhesive labels with liner (cut only liner between labels)
The cutter is designed to cut through paper-based media with a thickness
between 60 and 175 µm, which roughly corresponds to a paper weight
of 60 to 175 grams/m
2
(basis weight 40 to 120 lb.). The cutter should
not be used to cut through labels, because the adhesive will stick to the
shears, which can damage the cutter.
The optional label taken sensor cannot be used with the cutter.
The rotating cutting blade can be accidently activated while
the cutter is open. To avoid any risk of injury to fi ngers,
always switch off the power before loading media and/or
ribbon in a cutter-equipped printer.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
