Page #69 background imageLoading...
Page #69 background image
EasyCoder PX6i User’s Guide (Fingerprint version) 55
Chapter 6 — Setting Up the Printer
Recommended Feed Adjustments
The following settings allow printing from the top of the label. Minor
deviations from the recommended values may be required due to various
combinations of media types, roll size, type of media supply device, and
individual differences between printers.
Adjustment
type
8 dots/mm
203.2 dpi
11.81 dots/mm
300 dpi
Distance
in mm
Distance
in inches
Tear-Off (Straight-through)
Start adjust: -108 dots -160 dots 13.5 0.54
Stop adjust: 0 dots 0 dots 0 0
Peel-Off (Self-strip)
Start adjust: -80 dots -118 dots 10.0 0.39
Stop adjust: -40 dots -60 dots 5.0 0.20
Cut between labels w. gaps
Start adjust: -287 dots -424 dots 35,9 1.41
Stop adjust: +176 dots +260 dots 22.0 0.87
Cut fi x and variable length strip
Start adjust: -294 dots -434 dots 36.8 1.45
Stop adjust: +298 dots +440 dots 37.3 1.47
