EasyCoder PX6i User’s Guide (Fingerprint version) 49
Chapter 6 — Setting Up the Printer
Default Setup
The printer’s default setup is listed below (assuming no options installed):
Ser-Com "uart1:"
Baud rate 9600 bps
Character length 8 bits
Parity None
Stop bits 1 bit
RTS/CTS Disable
ENQ/ACK Disable
XON/XOFF, data to host Disable
XON/XOFF, data from host Disable
New line CR/LF
Receive buffer 1024 bytes
Transmit buffer 1024 bytes
Feedadjust:
Startadjust 0 dots
Stopadjust 0 dots
Media:
X-start 8 dots/mm = 203.2 dpi)
11.81 dots/mm = 300 dpi
24 dots
36 dots
Width 8 dots/mm = 203.2 dpi
11.81 dots/mm = 300 dpi
1320 dots
1948 dots
Length 8 dots/mm = 203.2
11.81 dots/mm = 300 dpi
1200 dots
1800 dots
Media type Label (w Gaps)
Paper type Thermal transfer
Ribbon constant 90
Ribbon factor 25
Label offset 0
Ribbon sensor (low diameter) 0 mm
Contrast ±0%
Paper sensor (low diameter) 0 mm
Print Defi nes:
Print speed 200 mm/sec.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
