EasyCoder PX6i User’s Guide (Fingerprint version) 37
Chapter 4 — Media Load
External Supply (Fan-fold), cont.
Use the upper slot in the rear plate
when the supply is at the same level
as the printer and when using peel-off
operation.
Use the lower slot in the rear plate when
the supply is placed lower than the
printer.
As an option, the printer can be fi tted
with a set of fan-fold guides in either
slot.
The outer guide is adjustable for various
media widths.
To Next Page
