EasyLAN 10i2 Ethernet Adapter User’s Manual
1-4
Physical Description
External EasyLAN 10i2 Adapter
LED
External power
supply connector
10BaseT
connector
Test
button
Parallel port
connector
EL10i010.eps
Internal EasyLAN 10i2 Adapter
O
I
10BaseT
connecto
r
LED
Test
button
EL10i011.eps
Part Function
10BaseT connector Connects the EasyLAN 10i2 adapter to a 10 Mbps Ethernet network
via a 10BaseT cable.
Parallel port connector
(external EasyLAN 10i2
adapter only)
Provides the external EasyLAN 10i2 adapter with a single
high-speed parallel port that can connect directly, without the need
of cabling, to an Intermec printer with a parallel port installed.
