EasyLAN 10i2 Ethernet Adapter User’s Manual
1-6
Ethernet II, 802.3, 802.2, 802.2 SNAP Frame types
Compatible with PCONSOLE, NWADMIN, PRINTCON, and other Novell
utilities
NetBEUI
Unix
Installing the EasyLAN 10i2 Adapter
Before you install the EasyLAN 10i2 adapter, make sure that you have the appropriate
Ethernet cable and power cable. Also make sure that you have loaded media and ribbon
into the printer. For help, see the quick start guide for your printer.
Connecting the EasyLAN 10i2 Adapter to Your Network
This section explains how to physically connect the internal or external EasyLAN 10i2
adapter to your network.
To connect the internal EasyLAN 10i2 adapter
1. Connect a 10BaseT cable into the 10BaseT connector. For help finding the 10BaseT
connector, see “Physical Description” earlier in this chapter.
2. Connect the other end of the 10BaseT cable into an Ethernet port for your network.
Although you can connect the external EasyLAN 10i2 adapter to several different
Intermec printers, the illustrations in the following procedure use the 7421.
To connect the external EasyLAN 10i2 adapter
1. Note the MAC address found on the underside of the EasyLAN 10i2 adapter. You
need this address during the configuration.
2. Turn off the printer.
3. Plug the parallel port connector into the printer’s parallel port.
