SECTION 7—BACK
Part No 1085787 39 Solara
™
and Solara
™
Limited
SECTION 7—BACK
 WARNING
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may result.
REMOVING/INSTALLING/ADJUSTING BACK
RELEASE CORD
NOTE: Refer to FIGURE 7.1 for this procedure.
 WARNING
After adjusting or replacing, ensure back is locked securely in place before using the
wheelchair.
REMOVING/INSTALLING BACK RELEASE CORD
1. Remove the back system from the wheelchair, if necessary. Refer to the Back Systems
Owner’s Manual for removing/installing procedures.
2. Press down on the white nylon lock to release the ends of the back release cord from
the cord fastener.
3. Feed one end of the back release cord through the cord fastener.
4. Remove the back release cord from wheelchair.
5. To install the new back release cord, reverse STEPS 2-4.
6. Adjust the back release cord to the desired tightness. Refer to Adjusting Back Release
Cord on page 39.
7. Reinstall the back, if necessary. Refer to the Back Systems Owner’s Manual for
removing/installing procedures.
ADJUSTING BACK RELEASE CORD
NOTE: The back release cord may be adjusted to a tight or loose fit to meet the need of the user.
1. Press down on the nylon lock to release the ends of the back release cord from the cord
fastener.
2. Adjust the back release cord to the desired tension.
NOTE: Some slack in the back release cord may be necessary to clear the back upholstery.
3. Press up on the nylon lock to lock the back release cord in place.
