SECTION 6—ARMS
Part No 1085787 33 Solara
™
and Solara
™
Limited
SECTION 6—ARMS
WARNING
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
REMOVING/INSTALLING DUAL POINT ARM
SOCKETS
NOTE: Refer to FIGURE 6.1 for this procedure.
REAR ARM SOCKET
NOTE: Before removing, note position of rear arm socket in back plate for proper reinstallation.
1. Do one (1) of the following:
A. Seat Pan - Remove the seat pan from the wheelchair. Refer to Removing/Installing
Seat Pan on page 22.
B. Seating System - Remove the seating system from the wheelchair. Refer to the
Seating Systems Owner’s Manual for installing/removing procedures.
2. Remove the two (2) hex screws, seat positioning strap (if applicable) and locknut that
secure the rear arm socket to the back plate.
3. Remove existing REAR arm socket from the wheelchair.
4. Install the two (2) existing hex screws through the new rear arm socket, seat
positioning strap (if applicable) and coved washers. Refer to FIGURE 6.1 for proper
hardware orientation.
5. Securely tighten the new rear arm socket to the back plate with the existing locknut.
6. Repeat STEPS 2-5 for opposite side, if necessary.
7. Do one (1) of the following:
A. Seat Pan - Install the seat pan onto the wheelchair. Refer to Removing/Installing
Seat Pan on page 22.
B. Seating System - Install the seating system onto the wheelchair. Refer to the Seating
Systems Owner’s Manual for installing/removing procedures.
FRONT ARM SOCKET
1. Do one (1) of the following:
A. Seat Pan - Remove the seat pan from the wheelchair. Refer to Removing/Installing
Seat Pan on page 22.
B. Seating System - Remove the seating system from the wheelchair. Refer to the
Seating Systems Owner’s Manual for installing/removing procedures.
