INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
93
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
The setting range: 0.00 Hz–P00.03 (max. output
frequency)
P08.37
Energy brake enable
This parameter is used to control the internal brake
pipe inside the VFD.
0: Disable
1: Enable
Note: Only applied to internal brake pipe.
1
○
P08.38
Threshold voltage of
dynamic brake
Set the starting bus voltage of dynamic brake,
adjust this value properly to brake the load
effectively. The default value changes with voltage
level
Setting range: 200.0–2000.0 V
380 V
voltage:
700.0 V
○
660 V
voltage:
1120.0 V
P08.39
Cooling fan running
mode
0: Normal mode
1: The fan keeps running after power on
0
○
P08.40
PWM selection
0x000–0x111
LED ones: PWM mode setting
0: PWM mode 1, 3PH and 2PH modulation
1: PWM mode 2, 3PH modulation
LED tens: Low-speed carrier frequency limiting
mode
0: Reducing the carrier frequency at low speed,
limiting the carrier frequency to 4 kHz when the
machine runs at low speed. This mode is valid only
for the closed-loop vector mode (P00.00=3).
1: No reducing the carrier frequency at low speed
Hundreds place: Dead-zone compensation method
setting
0: Method 1
1: Method 2
0: Method 1
1: Method 2
0x001
◎
P08.41
Overmodulation
0x00–0x91
Ones: Overmodulation selection
0: Invalid
1: Valid
Tens: Heavy overmodulation factor
0–9
0x01
◎
P08.42
Keypad data control
0x000–0x1223
LED ones: Frequency enable selection
0: Both ∧ / ∨ keys and digital potentiometer
adjustments are valid
0x0000
○
