INVT Goodrive35 Series

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
117
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
P15.25
Fault time of DP
communication
overtime
0.0 (invalid), 0.1–60.0s
When this function code is set as 0.0, this function is
invalid.
When the function code is set as nonzero value, if
the internal time between two communication
exceeds the communication overtime, the system
will report "PROFIBUS communication fault" (E-DP).
0.0 s
○
P15.26
Fault time of
CANopen
communication
overtime
0.0 (invalid),0.1–60.0 s
When this function code is set as 0.0, this function is
invalid
When the function code is set as nonzero value, if
the internal time between two communication
exceeds the communication overtime, the system
will report "CANopen communication fault" (E-CAN)
0.0 s
P15.27
CANopen baud rate
Set the data transmission rate.
0: 1000 k
1: 800 k
2: 500 k
3: 250 k
4: 125 k
5: 100 k
6: 50 k
7: 20 k
0
●
P16 Group Ethernet function
P16.00
Speed setting of
Ethernet
communication
0: Self-adapting
1: 100M full duplex
2: 100M semiduplex
3: 10M full duplex
4: 10M semiduplex
The function code is used to set the Ethernet
communication speed.
0
◎
P16.01
IP address 1
0–255
Set the IP address of Ethernet communication
The format of IP address:
P16.09.P16.10.P16.11.P16.12
For example: IP address is 192.168.0.1.
192
◎
P16.02
IP address 2
168
◎
P16.03
IP address 3
0
◎
P16.04
IP address 4
1
◎
P16.05
Subnet mask 1
0–255
255
◎
