Goodrive35 Series Closed-loop Vector Control VFD Function parameters
118
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
P16.06
Subnet mask 2
Set the subnet mask of Ethernet communication.
The format of IP subnet mask:
P16.13.P16.14.P16.15.P16.16.
For example: The mask is 255.255.255.0.
255
◎
P16.07
Subnet mask 3
255
◎
P16.08
Subnet mask 4
0
◎
P16.09
Gateway 1
0–255
Set the gateway of Ethernet communication
192
◎
P16.10
Gateway 2
168
◎
P16.11
Gateway 3
1
◎
P16.12
Gateway 4
1
◎
P17 Group Monitoring function
P17.00
Setting frequency
Display current set frequency of the VFD
Range: 0.00 Hz–P00.03
0.00 Hz
●
P17.01
Output frequency
Display current output frequency of the VFD
Range: 0.00 Hz–P00.03
0.00 Hz
●
P17.02
Ramp reference
frequency
Display current ramp reference frequency of the
VFD
Range: 0.00 Hz–P00.03
0.00 Hz
●
P17.03
Output voltage
Display current output voltage of the VFD
Range: 0–1200 V
0 V
●
P17.04
Output current
Display present output current of the VFD
Range: 0.0–5000.0 A
0.0 A
●
P17.05
Motor speed
Display the rotation speed of the motor.
Range: 0–65535 RPM
0 RPM
●
P17.06
Torque current
Display present torque current of the VFD
Range: -3000.0–3000.0 A
0.0 A
●
P17.07
Exciting current
Display present exciting current of the VFD
Range: -3000.0–3000.0 A
0.0 A
●
P17.08
Motor power
Display present power of the motor.
Setting range: -300.0%–300.0% (rated power of the
motor)
0.0%
●
P17.09
Output torque
Display the current output torque of the VFD; 100%
relative to rated torque of the motor. During forward
running, the positive value is the motoring state while
the negative value is generating state. During
reverse running, the positive value is the generating
state while the negative value is the motoring state.
Range: -250.0–250.0%
0.0%
●
