Goodrive35 Series Closed-loop Vector Control VFD Function parameters
120
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
P17.23
PID reference
Display PID reference value.
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback
Display PID feedback value
Range: -100.0–100.0%
0.0%
●
P17.25
Power factor of the
motor
Display the current power factor of the motor.
Range: -1.00–1.00
0.00
●
P17.26
Current running time
Display the current running time of the VFD.
Range: 0–65535 min
0 min
●
P17.27
Simple PLC and the
current step of the
multi-step speed
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
0
●
P17.28
ASR controller
output
This parameter is used to display the output value of
the automatic speed regulator (ASR). The value is
relative to the rated torque of the motor.
Range: -300.0%–+300.0% (the rated torque of the
motor)
0.0%
●
P17.29
initial identification
angle of
synchronous
machine
Display initial identification angle of synchronous
machine
Range: 0.0–359.9
0.0
●
P17.30
Phase compensation
of SM
Display SM phase compensation
Range: -180.0–180.0
0.0
●
P17.31
Reserved
P17.32
Reserved
P17.33
Exciting current
reference
Display the exciting current reference in the vector
control mode
Range: -3000.0–3000.0 A
0.0 A
●
P17.34
Torque current
reference
Display the torque current reference in the vector
control mode
Range: -3000.0–3000.0 A
0.0 A
●
P17.35
AC current
Display the value of inlet current in AC side
Range: 0.0–5000.0 A
0.0 A
●
P17.36
Output torque
Display the output torque value. During forward
running, the positive value is the motoring state while
the negative value is generating state. During
reverse running, the positive value is the generating
state while the negative value is the motoring state.
0.0 Nm
●
