INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Function parameters
133
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
is received, the operation mode is automatically
switched to speed control mode.
Bit7: Reference point calibration mode, setting
whether to perform position calibration every time
when the reference point is passed.
0: Calibrated when the reference point is passed for
the first time
1: Calibrated in real time
Bit8: Reserved
Bit9: Positioning completion signal setting
0: Electrical level signal
1: Pulse signal
Bit10: Pulse Z signal source
0: From the motor
1: From the spindle
Bit 11–15: Reserved
P22.01
Spindle orientation
speed
Speed for searching for the orientation start position
point. After the orientation start position point is
found, the operation mode is switched to the position
control mode and orientation is performed.
Range: 0.00–100.00 Hz
10.00 Hz
○
P22.02
Spindle orientation
DEC time
DEC time in spindle orientation.
It indicates the time the VFD takes to decelerate
from the max. output frequency (P00.03) to 0 Hz.
Setting range: 0.0–100.0s
3.0 s
○
P22.03
Spindle zero-point
position 0
You can set 4 spindle zero-point positions through
terminals (functions #46 and 47).
Range: 0–39999
0
○
P22.04
Spindle zero-point
position 1
Range: 0–39999
0
○
P22.05
Spindle zero-point
position 2
Range: 0–39999
0
○
P22.06
Spindle zero-point
position 3
Range: 0–39999
0
○
P22.07
Spindle indexing
angle 1
You can set 7 spindle indexing angles through
terminals (function #48, 49, and 50).
Range: 0.00–359.99
15.00
○
P22.08
Spindle indexing
Range: 0.00–359.99
30.00
○
