Goodrive35 Series Closed-loop Vector Control VFD Function parameters
134
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
angle 2
P22.09
Spindle indexing
angle 3
Range: 0.00359.99
45.00
P22.10
Spindle indexing
angle 4
Range: 0.00359.99
60.00
P22.11
Spindle indexing
angle 5
Range: 0.00359.99
90.00
P22.12
Spindle indexing
angle 6
Range: 0.00359.99
120.00
P22.13
Spindle indexing
angle 7
Range: 0.00359.99
180.00
P22.14
Spindle drive ratio
This parameter is used to set the deceleration ratio
of the spindle to shaft where the encoder is mounted.
Range: 0.00030.000
1.000
P22.15
Spindle zero-point
communication
setting
P22.15 is used to set the zero-point offset of the
spindle. If you set P22.03 as the zero point of the
spindle, the final zero point of the spindle is P22.03
plus P22.15.
Range: 039999
0
