Goodrive35 Series Closed-loop Vector Control VFD Function parameters
86
Functio
n code
Name
Detailed instruction of parameters
Default
value
Modif
y
BIT1: Bus voltage (V on)
BIT2: Input terminals state
BIT3: Output terminals state
BIT4: PID reference (% flickering)
BIT5: PID feedback value (% flickering)
BIT6: Torque reference (% flickering)
BIT7: AI1 (V on)
BIT8: AI2 (V on)
BIT9: AI3 (V on)
BIT10: HDI frequency
BIT11: PLC and the current stage in multi-step
speed
BIT12: Pulse counters
BIT13: Length value
BIT14–BIT15: Reserved
P07.08
Frequency
coefficient
0.01–10.00
Displayed frequency=running frequency* P07.08
1.00
○
P07.09
Rotation speed
coefficient
0.1–999.9%
Mechanical rotation speed =120*displayed running
frequency×P07.09/motor pole pairs
100.0%
○
P07.10
Linear speed
coefficient
0.1–999.9%
Linear speed= Mechanical rotation speed×P07.10
1.0%
○
P07.11
Rectifier bridge
module temperature
-20.0–120.0°C
●
P07.12
Inverter module
temperature
-20.0–120.0°C
●
P07.13
Software version
1.00–655.35
●
P07.14
Local accumulative
running time
0–65535h
●
P07.15
MSB of power
consumption
Display the power used by the VFD.
The power consumption of the VFD
=P07.15*1000+P07.16
Setting range of P07.15: 0–65535 kWh (*1000)
Setting range of P07.16: 0.0–999.9 kWh
●
P07.16
LSB of power
consumption
●
P07.17
Reserved
Reserved
●
P07.18
Rated VFD power
0.4–3000.0 kW
●
P07.19
Rated VFD voltage
50–1200 V
●
