Inxpect SRE 200 Series - 11.1 Technical data

11.1 Technical data
11.1.1 General specifications
Detection
method
Inxpect motion detection algorithm based
on FMCW radar
Frequency Working band:
l
for S201A model: 60.6-62.8 GHz
l
for S203A model: 61.2-63.4 GHz
Maximum radiated power: 16 dBm mean
EIRP
Modulation: FMCW
Detection
interval
From 0 to 5 m (from 0 to 16.4 ft)
Detectable
target RCS
(Human
detection)
0.17 m
2
Field of view Horizontal coverage programmable from
10° to 100°.
Vertical coverage:
l
S201A model: 20°
l
S203A model: 12°
Decision
probability
> 1-(2.5E-07)
CRT (Certified
Restart Timeout)
4 s
Guaranteed
response time
Access detection: < 100 ms *
Restart prevention: 4000 ms
WARNING! During the
real-time validation and
the download of the log
file, the response time is
not guaranteed.
Total
consumption
Max. 25.4 W (control unit and six sensors)
Electrical
protections
Polarity inversion
Overcurrent through resettable integrated
fuse (max. 5 s @ 8 A)
Overvoltage
category
II
Altitude Max. 1500 m ASL
Air humidity Max. 95%
Noise emission Negligible**
Note*: the value depends on the Electromagnetic
robustness level set through the Inxpect Safety
application, see "Electromagnetic Robustness" on
page52.
Note**: the A-weighted emission sound pressure
level does not exceed 70 dB(A).
11.1.2 Safety parameters
SIL (Safety
Integrity Level)
2
HFT 0
SC* 2
TYPE B
PL (Performance
Level)
d
ESPE Type (EN
61496-1)
3
Category (EN
ISO 13849)
3 equivalent
Class (IEC TS
62998-1)
D
Communication
protocol
(sensors-control
unit)
CAN complies with standard EN 50325-5
Mission time 20 years
MTTF
D
42 years
PFH
D
With Fieldbus communication:
l
Access detection: 1.40E-08 [1/h]
l
Restart prevention: 1.40E-08 [1/h]
l
Muting: 6.37E-09 [1/h]
l
Stop signal: 6.45E-09 [1/h]
l
Restart signal: 6.45E-09 [1/h]
l
Dynamic Configuration Switch: 6.37E-
09 [1/h]
l
Fieldbus controlled: 6.45E-09 [1/h]
Without Fieldbus communication:
l
Access detection: 1.30E-08 [1/h]
l
Restart prevention: 1.30E-08 [1/h]
l
Muting: 5.37E-09 [1/h]
l
Stop signal: 5.45E-09 [1/h]
l
Restart signal: 5.45E-09 [1/h]
l
Dynamic Configuration Switch: 5.37E-
09 [1/h]
l
Fieldbus controlled: 5.45E-09 [1/h]
SFF ≥ 99.89%
DCavg ≥ 99.46%
MRT
**
< 10 min
Safe state when
a fault occurs
At least one channel for each safety output
is in OFF-state. Stop message sent on
Fieldbus (if available) or communication
interrupted
Note*: the systematic capability is guaranteed only
if the user uses the product according to the
instructions of this manual and uses the product in
the appropriate environment.
Note**: the MRT considered is the Technical Mean
Repair Time, i.e., it takes in consideration
availability of skilled personnel, adequate tools and
spare parts. Considering the type of device, the MRT
corresponds to the time necessary for the device
replacement.
11.1.3 Ethernet connection (if
available)
Default IP
address
192.168.0.20
Default TCP port 80
Default netmask 255.255.255.0
Default gateway 192.168.0.1
11. Technical references
Inxpect SRE 200 Series | Instruction manual v1.5 DEC 2023|Inxpect SAF-IM-200S_5m_7_00047_en_v1.5|© 2021-2023 Inxpect SpA
105
