Inxpect SRE 200 Series - 3.3 Control unit inputs

LED
Status Meaning
SYS
F1
Steady green Normal behavior
Flashing green or
off
Contact Technical Support
F2
Off Normal behavior
Steady or flashing
yellow
Contact Technical Support
RUN
F3 (not used)
- -
F4
Off INIT state
Flashing green Pre-Operational state
Single flash green Safe-Operational state
Steady green Operational state
ERR
F5 Off Normal behavior
Flashing red Invalid configuration: General Configuration Error.
Possible reason: State change commanded by the master is
impossible due to register or object settings
Single flash red Local error: slave device application has changed the
EtherCAT® state autonomously.
Possible reasons:
l
a host watchdog timeout has occurred
l
synchronization error, the device enters the Safe-
Operational state automatically
Double flash red Application watchdog timeout: an application watchdog timeout
has occurred.
Possible reason: Sync Manager watchdog timeout
F6 (not used) - -
3.3 Control unit inputs
3.3.1 Introduction
The system has two type 3 dual channel digital inputs (according to IEC/EN 61131-2). Alternatively, the four
channels can be used as single channel digital inputs (category 2). The ground reference is common for all the
inputs (see "Technical references" on page104).
When using digital inputs, it is mandatory that the additional SNS input "V+ (SNS)" is connected to 24 V DC and
that the GND input "V- (SNS)" is connected to the ground in order to:
l
perform the correct input diagnostic
l
assure the system safety level
3.3.2 Input functions
The function of each digital input must be programmed through the Inxpect Safety application. The available
functions are the following:
l
Stop signal: additional safety-related function, which manages a specific signal to force all the safety
outputs (detection signals, if present) to OFF-state.
l
Restart signal: additional safety-related function, which manages a specific signal which enables the
control unit to switch to ON-state the safety outputs related to all the detection fields with no motion
detected.
l
Muting group “N”: additional safety-related function, which manages a specific signal, allowing the control
unit to ignore the information from a selected sensor group.
l
Dynamic configuration switch: additional safety-related function, which allows the control unit to select a
specific dynamic configuration.
l
Fieldbus controlled (if available): additional safety-related function monitors the input status through
Fieldbus communication. For example, a generic ESPE can be connected to the input, respecting electrical
specifications.
3. Get to know Inxpect SRE 200 Series
Inxpect SRE 200 Series | Instruction manual v1.5 DEC 2023|Inxpect SAF-IM-200S_5m_7_00047_en_v1.5|© 2021-2023 Inxpect SpA
21
