14
Inxpect SRE 200 Series| Instruction manual v1.5 DEC 2023 |Inxpect SAF-IM-200S_5m_7_00047_en_v1.5|© 2021-2023 Inxpect SpA
3. Get to know Inxpect SRE 200 Series
Contents
This section includes the following topics:
3.1 Inxpect SRE 200 Series 14
3.2 Control units 16
3.3 Control unit inputs 21
3.4 Control unit outputs 23
3.5 Sensors 26
3.6 Inxpect Safety application 28
3.7 Fieldbus communication (PROFIsafe) 30
3.8 Fieldbus communication (Safety over EtherCAT® - FSoE) 32
3.9 MODBUS communication 33
3.10 System configuration 34
Product label description
The following table describes the information contained in the product label:
Part Description
SID Sensor ID
DC "yy/ww" : year and week of the product manufacture
SRE Safety Radar Equipment
Model Product model (e.g., S201A, C201A)
Type Product variant, used for commercial purposes only
S/N Serial number
3.1 Inxpect SRE 200 Series
3.1.1 Definition
Inxpect SRE 200 Series is an active protection radar system that monitors the dangerous areas of machinery.
3.1.2 Special features
Some of the special features of this protection system are the following:
l
detection of current distance and angle of the targets detected by each sensor
l
customization of the detection field with advanced shapes (if available)
l
up to four safe detection fields to define different behaviors of the machines
l
programmable coverage angle for each detection field
l
rotation around three axes during installation to allow better coverage of detection areas
l
Safety Fieldbus to safely communicate with the PLC of the machinery (if available)
l
possibility to switch dynamically between different preset configurations (max. 32 through Fieldbus, if
available, and max. 8 with digital inputs)
l
muting on the entire system or only on some sensors
l
immunity to dust and smoke
l
reduction of undesired alarms caused by the presence of water or processing waste
l
communication and data exchange through MODBUS (if available)
