11.1.5 Sensor features
Connectors 2 5-pin M12 connectors (1 male and 1
female)
CAN bus
termination
resistance
120 Ω (not supplied, to be installed with a
bus terminator)
Power supply 12 V DC ± 20%, through control unit
Consumption Average 2.2 W
Peak 3.4 W
Degree of
protection
Type 3 enclosure, according to UL 50E, in
addition to IP 67 rating
Material Sensor:PA66
Bracket: PA66 and glass fiber (GF)
Frame rate 62 fps
Weight With 2-axes bracket: 300 g (10.6 oz)
With 3-axes bracket: 355 g (12.5 oz)
Shock/Bump For S201A model: in accordance with
IEC/EN 61496-1:2013 sec. 5.4.4.2 (IEC
60068-2-27)
For S203A model: in accordance with
IEC/EN 61496-1:2020 sec. 5.4.4.2 class
5M3 (IEC 60068-2-27)
Vibration For S201A model: in accordance with
IEC/EN 61496-1:2013 sec. 5.4.4.1 (IEC
60068-2-6)
For S203A model: in accordance with
IEC/EN 61496-1:2020 sec. 5.4.4.1 class
5M3 (IEC 60068-2-6 and IEC 60068-2-64)
Pollution degree 4
Outdoor use Yes
Operating
temperature
From -30 to +60 °C (from -22 to +140 °F)*
Storage
temperature
From -40 to +80 °C (from -40 to +176 °F)
Note*: in environmental conditions where the
operating temperature can reach values higher than
the supported range, install a cover to shield the
sensor from sun rays.
S201A model
