Parameter Min Max Default value
Settings > General
System Inxpect SRE 100 Series, Inxpect SRE 200
Series
Inxpect SRE 100
Series
Sensors model and type 5 meters range sensors, 9 meters range
sensors
5 meters range
sensors
Country Europe, Rest of the certified countries or
list of countries
Europe, Rest of the
certified countries
Application type selection Stationary, Mobile, Vehicle Stationary
Configuration
Number of installed sensors 1 6 1
Plane Dim. X: 1000 mm
Dim. Y: 1000 mm
Dim. X: 65000 mm
Dim. Y: 65000 mm
Dim. X:10000 mm
Dim. Y: 7000 mm
Position (for each sensor) X: 0 mm
Y: 0 mm
X: 65000 mm
Y: 65000 mm
Default position of
sensor #1:
X: 2000 mm
Y: 3000 mm
Rotation 1 (for each sensor) 0°, 90°, 180°, 270° 0°
Rotation 2 (for each sensor) 0° 359° 180°
Rotation 3 (for each sensor) -90° 90° 0°
Sensor installation height (for each sensor) 0 mm 10000 mm 0 mm
Detection Distance 1, Detection Distance 2
(for each sensor)
0 mm
Note: the minimum
value for the first
detection field with
distance > 0 is 500
mm for 3.x sensors
and200 mm for 5.x
sensors.
5000 mm
Note: the sum of all
the detection
distances (for each
sensor) cannot
exceed 5000 mm.
1000 mm
Detection Distance 3, Detection Distance 4
(for each sensor)
0 mm
Note: the minimum
value for the first
detection field with
distance > 0 is 500
mm for 3.x sensors
and200 mm for 5.x
sensors.
5000 mm
Note: the sum of all
the detection
distances (for each
sensor) cannot
exceed 5000 mm.
0 mm
For 5.x sensors - Detection area shape Classic, Corridor Classic
Angular coverage left (Classic shape) 0°
Note: the minimum
angular coverage
(left + right) is 10°
50° 45°
Angular coverage right (Classic shape) 0°
Note: the minimum
angular coverage
(left + right) is 10°
50° 45°
For 5.x sensors (Corridor shape) – Corridor
left
0 mm
Note: the minimum
corridor width (left +
right) is 200 mm.
4000 mm 500 mm
For 5.x sensors (Corridor shape) – Corridor
right
0 mm
Note: the minimum
corridor width (left +
right) is 200 mm.
4000 mm 500 mm
11. Technical references
