11. Technical references
Parameter Min Max Default value
Safety working mode (for each detection
field of each sensor)
Access detection and restart prevention,
Always-on access detection
Access detection and
restart prevention
Static object detection (for each detection
field of each sensor)
Enabled, Disabled Disabled
Restart timeout (for each detection field of
each sensor)
100 ms 60000 ms 4000 ms
T
OFF
100 ms 60000 ms 100 ms
Settings > Advanced
Detection field dependency Enabled, Disabled Enabled
Electromagnetic robustness Standard, High, Very High Standard
Static object detection sensitivity -20 dB +20 dB 0 dB
Settings > Advanced > Multi-control unit synchronization
Control unit channel 0 3 0
Settings > Anti-tampering
Anti-masking sensitivity (for each sensor) Disabled, Low, Medium, High High
Anti-masking distance (for each sensor) 200 mm 1000 mm 1000 mm
Anti-rotation around axes (for each sensor) Disabled, Enabled Disabled
Anti-rotation around axes - Enable specific
axis - Tilt (for each sensor)
Disabled, Enabled Disabled
Anti-rotation around axes - Enable specific
axis -Roll (for each sensor)
Disabled, Enabled Disabled
Anti-rotation around axes - Enable specific
axis - Pan (for each sensor)
Disabled, Enabled Disabled
Settings > Digital Input-Output
Digital input (for each input) Not configured, Stop signal, Restart signal,
Muting group “N”, Dynamic configuration
switch, Fieldbus controlled, System
recondition, Restart signal + System
recondition, Single channel (Category 2)
Not configured
Digital input channel (for each channel of
each input)
Not configured, Restart signal, Fieldbus
controlled, System recondition
Not configured
Redundancy mode Coherent, Inverted Coherent
Encoded channel Enabled, Disabled
Note: available only when both the digital
inputs are configured as Dynamic
configuration switch
Disabled
Digital output (for each output) Not configured, System diagnostic signal,
Muting enable feedback signal, Fieldbus
controlled, Restart feedback signal,
Detection signal "N", Static object detection
feedback signal, Detection signal group 1,
Detection signal group 2
Not configured
OSSD Pulse width Short (300 μs), Long (2 ms) Short (300 μs)
Short-circuit/Open circuit diagnostics Enabled, Disabled Disabled
Settings > Muting
Group for muting (for each sensor) None, Group 1, Group 2, both Group 1
Pulse width (for each input) 0 μs (= Period and
Phase shift disabled)
200 μs
2000 μs 0 μs
Period (for each input) 200 ms 2000 ms 200 ms
Phase shift (for each input) 0.4 ms 1000 ms 0.4 ms
