11. Technical references
Part Description
Dt Activation/deactivation delay. Less than 50 ms.
With pulse
Part Description
Diff Less than 100 ms. If the value is greater than 100 ms, the diagnostic alarm starts and the
system deactivates the safety outputs.
Muting signal
(group n) CH1
Muting signal
(group n) CH2
Interchangeable channel.
Muting status They are enabled as long as both the input signals follow the configured muting parameters
(pulse width, period, and phase shift).
Dt Activation/deactivation delay. Less than three times the period.
