PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 31 of 141
88292-EN, Rev D
System Components
Laser Console
Houses the key switch, emergency laser stop button, fiber ports, laser fiber and electronics
cable, 532 nm or 577 nm single wavelength laser, control electronics and power supply.
Touchscreen LCD Control Panel
Provides controls for selecting treatment parameters and displays for monitoring system
information.
