PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 33 of 141
88292-EN, Rev D
Micro Manipulator
Provides auxiliary input for laser position. The aiming beam/treatment beam can be moved
up/down/left/right in same direction as the micro manipulator (MM) moves. The movement is
centered around any position offset (if any) introduced by the 3D controller.
The micro manipulator will return to mechanical center when released. There maybe a few
counts from true center after released the Micro Manipulator, the user can press Home
button to make it center.
•
The Micro Manipulator is disabled during the laser treatment
Power Knob
The Power Knob located below the Micro Manipulator provides auxiliary input for laser
power.
User can adjust power up or down by rotating the power knob similar to the touch screen
power up or down. Clockwise rotation increases the power and Counter clockwise rotation
decreases the power.
•
The Power Knob is disabled during the laser treatment
