Iridex PASCAL Synthesis - Single Spot

PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 50 of 141
88292-EN, Rev D
Single Spot
Primary pattern
Secondary pattern
Single Spot
Not available
General Use
• PRP, retina tears, retina detachments, iridotomy, trabeculoplasty, LIO
Pattern
Spot Diameter
Repetition Rate
EPM %
Single Spot
50μm
Off, 1.0Hz to 8.0Hz
10 to 95
100μm
200μm
400μm
The Single Spot pattern can be used with the slit lamp or an optional laser indirect
ophthalmoscope (LIO). Spot diameter and repetition rate settings are adjustable.
NOTE
• The full range of settings is not available for every combination of parameters.
Endpoint Management Features
Endpoint Management Off
or Disabled
Endpoint Management On/
Landmark On
Endpoint Management On/
Landmark Off
Single-full-power spots (red-
100%)
Single full-power spots (red-
100%)
Single endpoint spots
(orange-xx %)
NOTE
• The Endpoint Management feature is not available with the LIO.
