PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 32 of 141
88292-EN, Rev D
Slit Lamp (model SL-PA04)
Integrated slit lamp connection. Service personnel will connect laser system to slit lamp.
PASCAL Synthesis Slit Lamp PA04
Footswitch
Activates laser treatment beam when depressed while system is in READY mode.
Footswitch marked with IPX1 is suitable for general or office use.
Door Interlock Plug
Disables laser if treatment room doors are opened or interlock plug is removed. Use is
optional; however, interlock plug must be inserted for laser to operate.
Aperture/slit
length adjustment
Illumination intensity
adjustment
