PASCAL
®
Synthesis Ophthalmic Scanning Laser Systems Page 49 of 141
88292-EN, Rev D
Posterior Pattern Descriptions/Pattern Parameters
There are three groups, fifteen posterior pattern types in total. The choice of pattern
determines which parameters (e.g., radius, curvature, repetition rate, etc.) display on the
touchscreen control panel, as well as the range of values for each parameter on the
treatment screen.
•
When user selects different group among Single Spot, Pattern and EpM, the setting
for each parameter for the pattern will be reset to the default.
•
When user selects a different pattern within the same group, the setting for each
parameter will keep the same unless the value is not within the range for the selected
pattern. In that case, the setting will be reset to the default.
