<AIM> - press to turn on/off aiming beam in STANDBY
B
<Spot Diameter> - press up/down buttons to adjust
C
<Spacing/Curvature> - press up/down buttons to adjust (when Applicable)
D
<Rep Rate> - press up/down buttons to adjust (when Applicable)
NOTE
• Parameter controls only show on screens when applicable to the pattern selected.
See the section “Pattern Descriptions/Pattern Parameters” for detailed information.
