Endpoint Management Features
Pattern
Type
Endpoint Management
Off or Disabled
Endpoint Management
On/ Landmark On
Endpoint Management
On/ Landmark Off
All full-power spots (red-
100%)
All full-power spots (red-
100%)
All endpoint spots
(orange-xx %)
1x2,
2x1,
2x2
Single-
column
or single
row
arrays
with at
least 3
spots
All full-power spots (red-
100%)
Two full-power spots (red-
100%); remaining
endpoint spots (orange-xx
%)
All endpoint spots
(orange-xx %)
All full-power spots (red-
100%)
Four full-power spots
(red- 100%); remaining
endpoint spots (orange-xx
%)
All endpoint spots
(orange-xx %)
All other
arrays
