Enhanced Octants
Primary pattern
Secondary pattern
15ms EpM
Enhanced
Octants
Not available
See the section “Posterior Pattern Description/Pattern Parameters” for the detailed
information on the Enhanced Octants pattern.
Auto-Transition Feature
In 15ms EpM Enhanced Octant pattern, if Array or Hexagon pattern is selected in Auto-
Transition after Enhanced Octants at Physician Preferences screen, it allows the user to
transition to the selected pattern automatically after treating the last subset of Octants and to
STANDBY mode.
In the case of Array pattern selected
In the case of Hexagon pattern selected
Auto-Transition after Enhanced Octants
